DG-SC2100/DG-SC2100W User Manual
68
Moving the mouse cursor over certain sections of the screen provides the names of the
buttons
Below are the detailed descriptions of all buttons:
Item Description
Video displaying
area
The image of all connected cameras will be displayed here.
Language Select a language from this dropdown menu to change display
language.
Display layout Change camera image display layout (Click a layout icon to
change camera display layout). There are 8 kinds of available
display layouts.
Full screen Click this button to switch to full screen mode (only display
all camera’s image), press ‘ESC’ key to quit full screen mode.
Scan Click this button and the IP camera surveillance software will
switch displaying the image of all connected camera
automatically. Click this button once to activate scan function
(scan icon will become blue ), click again to stop scanning
(scan icon will become white ).
PTZ control
There are 8 directions in PTZ control ring. If the camera you
connect supports PTZ, you can use PTZ control ring to change
the direction that camera points to.
This function is only available for supported cameras.
Home
Click this button to return the camera to ‘Home’ (default)
position.
This function is only available for supported cameras.
Recording Start video recording.
Setup Software / camera configuration.
Playback Playback a recorded video file.
