Digital Dream DDCS V3.1 User Manual

Digital Dream Standalone Motion Controller DDCS V3.1 DDCS V3.1 Users Manual
Page -47
Note: “All Axes Go To Zero” will not zero Z axis,Z will go to a safety height as defined by
parameter #82.
3.3.5.2 Zero
Figure 3-45 All Axis Go To Zero
Figure 3-46 Zero Mode
B: All Axes Go To Zero:
After pressing to go to 2nd Mode,and pressing to go to the Go To Zero
mode,then we just press again to let all axes go to zero.Then there is no editing window
pop up,system just do the action of all the axes “Go To Zero”.
X-
GOTO 0
X-
GOTO 0
Shift
In Ready Mode,Press the key to enter into the 2ND Mode.
Press one time,the system turns to Zero mode,as Picuture 3-46 shows.
Shift
Y
-
ZERO
