The following rates require license-based Test Options
• 1G/10G LAN - Select SONET or SDH tab, then Interface and
choose 10G LAN. Then select Packet tab.
• 10G WAN - Select SONET or SDH tab, then Interface and
choose STM-64 or OC-192. Select Mapping and choose “AU-
4-64c Ethernet WAN” or “STS-192c Ethernet WAN”. Then
select Packet tab.
• 11G (10G LAN over OTU-1e/OTU-2e) - Select OTN tab, then
Interface and choose OTU-1e or OTU-2e. Select Mapping and
choose 10G LAN. Then select Packet tab.
• GFP - Select SONET or SDH tab, then set Interface and Map-
ping to any configuration that is applicable to GFP. Select Pay-
load Pattern and choose GFP. Then select Packet tab.
4. For HD Ethernet (T1, T1T6) module interface...
• All rates - Select HDEnet tab, then select the Port button and
choose the required port. All ports operate simultaneously but
they are set up one at a time. Ports 1-4 are Gigabit Ethernet
optical. Ports 5-12 are 10/100/1000BaseT. Port 13 is 10Gigabit
Ethernet optical.
5. Turn Laser on in upper left of screen, if applicable.
6. Confirm Rx power level is within the NIC’s specifications. Power
level is indicated just below the Laser is On button in the upper left
of the screen.
7. Confirm that link state is green and that no red LEDs are visible in
Alarm and Status indicators. Note that a red LED indicates a real-
time alarm/error condition. The red text indicates history, that the
condition has existed during the current test.
8. Select Config, then Set. Select Interface then choose required inter-
face, if applicable.
9. Change auto-negotiation and port addresses if required.
