Document No. CO 004844K
36
5. Under Label Information, enter a new name in the PP
Assigned text field. For example, “DS3 TAMPA”. (When
using the touch screen, select to open a keypad)
6. Select Update List to add the name to the User Defined
Name column in the list box.
7. Repeat steps 4 through 6 to continue adding user-defined
names.
8. To complete the process, select Save List.
9. Notice the names on the select protocol processor tabs
update, as well as their names listed in the GoTo menu.
Tab label names are set back to defaults during a software upgrade.
Make a note of these names to be re-applied after an upgrade
To restore default tab names on the Go To label:
1. Under Label Preferences, select .
2. Select Save List.
Touch Screen Calibration
Touch screen calibration is performed on all portable test sets prior to
shipping from the factory. However, if your test set’s touch screen
requires recalibration, perform the procedure described below.
Although touch screen calibration can be performed using your finger, a
pointing device such as a stylus is recommended for greater accuracy.
To calibrate the touch screen:
1. Select the System tab and choose Misc. The Miscellaneous
functions appear.
2. Select the Recalibrate Touch Screen button. This button appears
in the touch screen’s upper-left corner and in the lower-right
corner.
