To edit the notes, the test unit must be placed in locked mode by the
immediate user.
1. Choose the desired protocol processor and select the Lock icon.
The Lock/Unlock dialog box appears.
2. Select and/or and make appropriate
changes using the Enter User String keyboard. Select Enter.
3. Select Exit.
Saving Customized Setting Configurations
This function allows you to save a customized configuration for all
protocol processor Transmit or Receive settings.
The Save button saves settings for all protocol processors. For example,
when a customized settings configuration is saved while in a particular
protocol processor mode (for example, STM-4), the settings currently
configured for other protocol processors (for example, E1, E3, STM-16,
etc.) will also be saved with that setting configuration.
To save a configuration:
1. Create a test configuration using the Transmit and Receive
Settings screens.
2. Once you are done, select from the common function
buttons.
3. Select Save This Test Set, and the File Browser window appears.
4. Select File Name. A keypad appears.
5. Enter a name for the new configuration and select Enter when
done.
6. Select OK. The file is saved with an automatic file extension
of.set and appears in the File List.
