56
195
Enable the display-segment-test? - When this option is enabled then in case of an error the message ‘ERROR’ ‘DISPL’ will appear on
the display. The display-segment-test is done on the moment of passing from Stopped to Hired. The lights tested are: TAXI and light 1
to light 4.
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
196
Block taxi-meter on disp.-segment-error? - At the end of the current fare should the taxi-meter be blocked in case of a display-segment-
error?
The allowed answer is either: 0 (No: don’t block) or: 1 (Yes: block).
No / Yes
197
Disable the display-dim func! on? - The possibility to dim the display should be disabled? General: the allowed answer is either: 0
(No: enable dimming) or: 1 (Yes: disable dimming). The intensity itself can be programmed with Q.198.
No / Yes
198
Intensity displ.-dim func! on is 50% or 75%? - The intensity of the display can be programmed to have one of two values: 50% or 75%.
The allowed answer is either: 0 (No: 50%) or: 1 (Yes: 75%). The display-dim function can be enabled by programming Q.197.
0=50%
1=75%
199
Fixed Cross-speed: the calculation of the cost of a fare is either based on time or based on distance.
Below a certain velocity it is convenient to calculate the cost based on time (and not on distance). Above that velocity however it is
convenient to calculate the cost based on distance (and not on time). This velocity is the so called cross-speed. At this velocity the
calculated cost is the same for both time and distance. The velocity is given in Km/h with an accuracy of 1 Km/h. The allowed value
goes from 0 (min) to 255 (max).
A fi xed cross-speed can be obtained by programming a value between 1 and 255 (Km/h). The value 0 is a special case (default). If 0 is
programmed then the cross-speed is calculated automatically based on Q.2/3/4 and Q.5/6/7.
0 - 255
km/h
200
Alarm-velocity speedometer: this is the velocity above which an acoustical alarm-signal is produced.
If the (over-) velocity is maintained for at least 5 sec. Then it gets registered in the statistics. The registration is maintained for the last 40
events. So, at event n. 41 event n. 1 gets lost. The alarm-velocity is given in Km/h with an accuracy of 1 Km/h. The allowed value goes
from 0 (min) to 255 (max). The value 0 is a special case (default). If 0 is programmed then the alarm speedometer is disabled.
0 - 255
km/h
201
Speedometer velocity-step: this is the step-amount (of velocity) with which the threshold of the speedometer gets decremented or
incremented every time key F4 (dec.) or key F5 (inc.) is pressed. The velocity-step is given in Km/h with an accuracy of 1 Km/h.
The allowed value goes from 0 (min) to 255 (max).
0-255
202
Enable manual setup of speedometer? - Should the possibility to setup the speedometer manually be enabled?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
203
Show real-! me speed on display? - Should the real-time speed of the car be shown on the secondary display?
No / Yes
204
Show distance on display? - Should the (real-time) distance of the car be shown on the secondary display?
No / Yes
205
Enable the Euro Conversion?
No / Yes
206
Must the trip total amount be printed in Euro as well?
No / Yes
207
During sums, extras inser! on is not allowed?
No / Yes
208
During sums, locks F5 (to avoid summing ! me to be extended)
No / Yes
209
Disable the sum separa! on with F5?
No / Yes
210
Star! ng-hour of dim-func! on: this is the moment (whole or half hour) starting from which the display will be dimmed (according to
Q.197 and Q.198). The time is given in whole hours with an accuracy of 1 hour. The allowed value goes from 0 (min) to 23 (max). It is
also possible to specify half hours. In order to do this add 100 to the programmed value. For example, to program the hour 22:30 use
the value 122.
No / Yes
211
Ending-hour of dim-func! on: this is the moment (whole or half hour) starting from which the display will have normal intensity (according
to Q.197 and Q.198). The time is given in whole hours with an accuracy of 1 hour. The allowed value goes from 0 (min) to 23 (max).
It is also possible to specify half hours. In order to do this add 100 to the programmed value.
For example, to program the hour 22:30 use the value 122.
No / Yes
TAXI -LIGHT
212
Enable taxi-light ON in day-! me? - Should it be possible for the taxi-light to be ON during the day-time?
The allowed answer is either: 0 (No: disabled) or: 1 (Yes: enabled).
No / Yes
213
The taxi-light must " ash? - If Yes the taxi-light will fl ash. The allowed answer is either: 0 (No: no fl ash) or: 1 (Yes: fl ash).
No / Yes
