DIGITIZE DET-16 - Setting 3 Zone Alarm Code Rounds; Setting 4 Zone Trouble Code

System Programming Digitize Inc.
20 700271-0001 Rev. G 05/13
Default Settings:
Zone 1 1 Zone 9 1
Zone 2 2 Zone 10 2
Zone 3 3 Zone 11 3
Zone 4 4 Zone 12 4
Zone 5 5 Zone 13 5
Zone 6 6 Zone 14 6
Zone 7 7 Zone 15 7
Zone 8 8 Zone 16 8
5.4.3 Setting 3 Zone Alarm Code Rounds
This function sets the number of times a Zone Box Number & Alarm Code will be sent when
a zone is placed in an ALARM condition. The number of rounds can be set from 1 to 4.
Default Settings: For ALL Zones: 4 Rounds.
5.4.4 Setting 4 Zone Trouble Code
Each zone of the DET-16 panel can be programmed with a completely independent Trouble
Code. The Zone Trouble Code can be set from 0 – 9. When a zone goes into a Trouble
condition, the DET-16 will first transmit the box number followed by the Zone Trouble
Code. For example: Zone 1 is placed in Trouble, the panel would send 22221. The “1” is the
trouble code.
Default Settings:
