Digitize Inc. Det-16 Programming Utility

700271-0001 Rev. G 05/13 43

4. If the panel and computer connect properly, the upload procedure will begin and the

progress will be reported in the window.

If the panel and the computer fail to connect, the following window will open. Check the

connection of the USB cable and try again.

5. The following window signals the successful end of the upload procedure.

6.3.11 Downloading Settings from the Det-16

1. Connect a USB cable from the Det-16 panel to the laptop computer.

2. Select “Download Settings from Det-16” from the Transfer Pull down Menu.

3. A new window will open. Press the Reset button on the Det-16 panel to start the

download.
