Digitrax Zephyr - Page 45

44
B
A
JUMP 1
GROUND
RAIL B
JUMP 2
PROG A
RAIL A
PROG B
LOCONET
R
POWER IN
15V AC
2.5 AMPS
PS315 Power Supply Plugged Into Wall Outlet
Layout Power District (Double Gapped)
Rail A
Rail B
DO NOT USE WITH TRACK
OVER 16 VOLTS
B
A
JUMP 1
GROUND
RAIL B
JUMP 2
PROG A
RAIL A
PROG B
LOCONET
R
POWER IN
15V AC
2.5 AMPS
PS315 Power Supply Plugged Into Wall Outlet
Layout Power District (Double Gapped)
Rail A
Rail B
DO NOT USE WITH TRACK
OVER 16 VOLTS
DCS50 running as the system’s command station With the original factory setting of Option Switch 02 set to "t"
DCS50 running as a booster and throttle Option Swtich 02 set to c.
Double Gaps Between Layout Power Districts
LocoNet Cable
Adding A Second DCS50 To Your Layout
