ICS-1000 Ion Chromatography System
2-28 Doc. 031879-01 3/03
DS6 Heated Conductivity Cell Components
The cell front cover provides CELL IN and CELL OUT fittings for
connecting the cell to the suppressor (see Figure 2-4
). The remaining cell
components are mounted behind the component panel. To replace, the cell
remove the screws on the cell front cover and pull the entire cell assembly
out through the component panel. See Section 5.9
for cell replacement
instructions.
