Operating Instructions RF-2000
35
Please note:
If the output changes abruptly at the beginning or the end of the
spectrum plot, the mark may not be recorded.
Mark : approx. 4mV (INT)
approx. 4mV (REC 10mV)
approx. 0.4mV (REC 1mV)
Output time T is as follows:
T = (SCAN END - SCAN BGN) /Plot speed (1, 5, or 10nm/s)
For example, when the range from 200nm to 350nm is to be output at the plot speed
of 5nm/s (PLOT SPD = 2):
T = (350 - 200) nm/5nm/s = 30s
Please note:
Data in any file which is not scanned cannot be output. If data
does not exist in the specified file, "DATA NOT EXIST"
message is displayed. Similarly, plotting is not possible when
data does not exist in the background file (SCAN FILE = 0).
