Operating Instructions RF-2000
37
In 5.1 minutes, sensitivity is set at 3 (Low).
EX(nm) EM(nm) Data
5.10 GAIN 3
Right after that, gain is set at 3 (x 16).
EX(nm) EM(nm) Data
5.10 RESP 2
Right after that, response is set at 2 (0.5s).
EX(nm) EM(nm) Data
5.10 RANG 5
Right after that, range is set at 5 (x 16).
EX(nm) EM(nm) Data
10.00 MARK
In 10 minutes, marking on the recorder is performed.
EX(nm) EM(nm) Data
20.00 SCAN 0
In 20 minutes, wavelength scanning is executed and data is stored in file 0. (Type,
wavelength range and speed of the scan should be set in AUX. FUNC in advance.)
EX(nm) EM(nm) Data
999.99 LOOP 2
In 999. 99 minutes, the timer is reset to 0 and the time program is repeated from the
beginning. The time program is executed twice and stopped.
• Since the above time program is just an example for explanation and may not be
adequate for actual measurement.
• The screen display does not change as shown in the above example
synchronously with the time program. Check the program in the edit mode.
5.4.2 Explanation of display screen
It is necessary to enter the edit mode to edit a time program.
(1) Press shift + edit and the following is displayed.
EX(nm) EM(nm) Data
10 USED 22
LEFT
10: Number of steps already set.
22: Number of available steps left.
The above example shows that the time program is set for 10 steps and there are 22
steps available.
