DirecTV Advanced Installation Meter User Manual

1 Getting Started AIM User’s Manual
15
2 Carefully separate the front housing and the back housing, and place the unit on
a flat work surface.
3 Using the Phillips-head screwdriver, remove the 4 screws on the battery cover
and remove the cover. See Figure 6.
4 Disconnect the battery connector from the circuit board. See Figure 7.
5 Remove the battery from the back housing.
Figure 6 Removing the Battery Cover
Screws
Screws
Battery cover
Figure 7 Removing the Battery
Battery
Battery connector
Snap cover
