Controls - 54 JT40/JT40 All Terrain Operator’s Manual
Right Control Console
2. Outer rotation pressure
gauge
Displays outer rotation
pressure graphically and
numerically.
3. Drilling fluid rotation
speed gauge
Displays drilling fluid rotation
speed graphically and
numerically.
4. Drilling fluid rotation
pressure gauge
Displays drilling fluid rotation
pressure graphically and
numerically.
5. Inner rotation speed
gauge
Displays inner rotation speed
graphically and numerically.
6. Inner rotation pressure
gauge
Displays inner rotation
pressure graphically and
numerically.
7. Inner rotation hour
meter
Displays inner rotation hours
since last manual reset.
See “Inner rotation hour reset key (AT
only)” on page 53.
8. Day/Night mode key Press from main screen to
toggle between day and night
modes.
9. Inner rotation hour
reset key
Press and hold for five
seconds to reset inner
rotation hours.
10. ESID status display key Displays when unit detects an
error with ESID system.
11. Stationary exhaust
cleaning key
Press from main screen
(gauges) to force stationary
exhaust cleaning.
NOTICE:
• Failure to complete an exhaust
cleaning when required can
cause damage to the engine.
• A typical exhaust cleaning cycle
will take approximately 35
minutes.
• Ensure machine is away from
combustible material and engine
is set at low throttle before
initiating exhaust cleaning.
• A pop-up message will appear
when exhaust cleaning is
selected. Follow on-screen
prompts to complete the process.
Item Description Notes
