JT40/JT40 All Terrain Operator’s Manual Controls - 55
Right Control Console
12. Main menu key Press from main screen
(gauges) to select main
menu.
See “Main Menu” on page 56.
13. Carve window Displays the carve window,
set by operator.
IMPORTANT: This gauge replaces
the inner rotation speed/pressure
gauge when the carve function is
selected. See “Use AutoCarve” on
page 138.
14. Thrust pressure gauge Numerically and graphically
displays thrust pressure.
15. Carriage distance
display
Numerically displays distance
of the carriage.
16. Carriage speed display Numerically displays speed of
the carriage.
Item Description Notes
