7.2 Floor guide installation
The floor guides must be made of an antifriction material such as PVC, NYLON, TEFLON. The
length of the floor guide should not be greater than the overlap of between the fixed and mobile
door wing and must not enter the doorway.
The measurements of the code KPAM45 floor guide for telescopic door wings are indicated in the
diagram.
The measurements of the code KAMC16/KAMT16 floor guide
for telescopic door wings are indicated in the diagram.
7.3 Belt stop installation
