12. Example of connection
12.1 Combined opening and safety sensor + safety sensor on opening
With these connections, the automation opens and makes a reversal safety contact on the passage
opening with a command from the internal and/or external sensor.
Opening safety is guaranteed by the auto-control side sensors.
The electrical connections must be made when the mains power supply is switched off.
INNER SENSOR
OUTER SENSOR
ATTENTION: if the sensor is connected to the terminals of the control unit as shown
below and not to the dedicated plugs, as indicated in chapter 8.1, DO NOT cut this
cable side that must be connected to the SENSOR:
i
NB: If only one sensor is connected, refer to the sensor connections (1).
PASAA2 (1)
White
Brown
Green
Yellow
Pink
Blue
Red
Black
17
15
16
15
9
15
17
13
White
Brown
Green
Yellow
Pink
Blue
Red
Black
PASAA2
(2)
14
8
5
8
11
8
14
13
SENSOR
MCU
Set the selection DIP switches on sensor PASAA2 as shown below:
1034 11 12 14
ON
