5
EN
IP2348EN
2. T
ech
nical
da
ta
Ditec DAS200T
Ditec DAS200TRF
Ditec DAS200TRG
Power suppl
y
110V~ / 240V~
50/60Hz
110V~ / 240V~
50/60Hz
Power suppl
y rated
power (PS)
150W
150W
Max Opening speed
(4 door wings)
1,6m/s
1,6m/s
Maximum load
120kg/wing( 1+1 wing)
80kg/wing ( 2+2 wings)
120kg/wing( 1+1 wing)
80kg/wing ( 2+2 wings)
Intermittence
S3=100%
S3=100%
T
emperatur
e
-20°C +50°C
-20°C +50°C
Degree of pr
otection
IP20
(FOR INTERNAL USE ONL
Y)
IP20
(FOR INTERNAL USE ONL
Y)
Control panel
(MCU/MCU-ER)
1DAS20HDQE
1DAS20RGQE
Acc
essories power
supply
24V
1A
24V
1A
Durabi
lity test
1.000.000 cycles
1.000.000 cycles
TYPE OF USE
Ditec DAS200T
Ditec DAS200TRF
Ditec D
AS200TRG
Sliding door automation
Escape route with rubber band
opening system
Escape route with r
edundant
system
4
6
Table of Contents
Table of Contents
2
1 General Safety Precautions
3
Declaration of Incorporation of Partly Completed Machinery
4
2 Technical Data
5
3 Standard Installation
6
4 Main Components
7
5 Installing the Automation
8
Installing / Removing the Cover
8
Installation/Removal of the Cover if Installed Side Presence Sensor
8
Removing the Front Casing
9
Rear Operator Installation
9
Front Operator Installation
10
Installation Examples Using Supplied Wing Anchoring Brackets
10
Installing / Removing the Cover
11
6 Example of Box Fastening
13
Examples with Wing Connection Bracket DASTAC16
13
Example with Wing Connection Bracket DAST30
14
Example with Wing Connection Bracket DASTAC
14
7 Preparation of the Glass Door Wing
16
Installing and Adjusting the Door Wings
17
Floor Guide Installation
20
Belt Stop Installation
20
Checking and Adjusting the Belt Tension
21
Sensor Positioning on the Cover
21
External Sensor Cable Fixing
21
8 Electrical Connections
22
Standard Electrical Connections
23
Control Panel Commands
25
Commands
25
DAS902MP Plus Module (Optional)
27
DAS902MP Commands
28
9 Adjustment and Selection of Control Functions
30
Display Test
31
Status Indication on the Display
31
10 Start up
32
Parameters
35
Default Chapter
35
Configuration Parameters According to Function
35
Parameter Description Range
35
High Speed Closing 10÷80Cm/S
38
High Speed Opening 10÷80Cm/S
38
Hold Open Time 00÷60S
38
Key Hold Open Time 00÷60S
38
Low Speed 05÷80Cm/S
38
Main Control Board Parameters
38
Partial Hold Open Time 00÷60S
39
Push & Go Hold Open Time 00÷60S
39
12 Example of Connection
49
Combined Opening and Safety Sensor + Safety Sensor on Opening
49
Interconnection of Operators
51
Interconnection Cable
51
Hardware Configuration for Interconnection
51
Parameter Configuration for Interconnection
52
Operation Mode Selector (OMS) Functionality
52
Synchronization
53
Interlock
53
13 Troubleshooting
55
Active Error Indication
56
14 Routine Maintenance Plan
60
