DITEC DAS200TRF - Standard Installation

1
3
2
A
5
4
4
6
EN
IP2348EN
3. Standard installation
Ref. Description
1 Automation for sliding doors
2
3
Combined opening and safe closing sensor
4 Safe opening sensor
5 Program selector
A Connect the power supply cable to a type-approved omnipolar switch with category III insulation and
a contact opening distance of at least 3mm.
The connections to the mains and low voltage wires must be made on an independent channel se-
parated from the connections to the command and safety devices (SELV= Safety Extra Low Voltage).
