25
EN
IP2348EN
DO NOT USE
Central presence sensor test
Inner impulse (motion) monitoring
Side presence sensor test
Side presence sensor 2
Stop
Side presence sensor 1
Blocking device
Blocking device
(+) 24V
Inner side opening
(-) 0V
(+) 24V
Key opening
Central presence sensor 2
Central presence sensor 1
(-) 0V
(+) 24V
Outer side opening
Jumper the unused N.C. contacts
(-) 0V
blocking device connection
(main coil)
}
7
6
5
4
3
2
1
14
13
12
11
10
9
8
17
16
15
20
19
18
(use this contact if used only one sensor)
(use this contact if used only one sensor)
8.2 Control panel commands
NOTE: Power supply output for external
accessories 24V .
1 A: DAS200T-DAS200TRF-DAS200TRG.
The maximum absorption of corresponds
to the sum of all terminals power supply
output (1-7; 8-14; 15-17)
8.2.1 Commands
Contact Description
1
2
(ref. parameter 27)
N.C.
SIDE
PRESENCE
SENSOR 1
Connect side presence sensor 1 as shown in the example in
paragraph 12.
1
3
(ref. parameter 46)
N.C. STOP
The opening of the safety contact causes the current operation
to stop.
WARNING: when the contact closes again, the door closes.
WARNING: The emergency opening (battery 12V), is priority
(=door opens in case of mains power failure even if STOP
contact is open).
1
4
(ref. parameter 28)
N.C.
SIDE
PRESENCE
SENSOR 2
Connect side presence sensor 2 as shown in the example in
paragraph 12.
1
5 N.O.
OUTER SIDE
OPENING
Connect the external sensor as shown in the example in pa-
ragraph 12.
The closure of the contact activates the door opening operation.
6
(ref. parameter 29)
SIDE
PRESENCE
SENSOR TEST
Connect the test clamp of the side sensors.
Clamp 6 activates a test on the side safety sensors before every
operation.
If the test fails, an alarm message appears on the display.
The door will open and remain open until the fault is cleared
1
-
7 +
POWER SUPPLY
TO
ACCESSORIES
24 V accessories power supply.
