DITEC DAS200TRF User Manual

32
EN
IP2348EN
i
NOTE: for DAS200TRF follow the start up procedure indicated in the DAS200RFKA
kit manual.
Before performing any type of operation, make sure that the automation is turned off
and the batteries are disconnected.
Start-up and adjustment must be performed in the following order when the automation is installed:
1. Connect the accessories, opening and safety sensors, blocking device, batteries and selector.
2. Jumper the safety contacts 1-2, 1-3, 1-4, 8-9, 8-11 on the control panel and 1-5 on plus
module DAS902MP, if not used.
3. Connect the mains power supply to the automation.
4. Set the following parameters:
Parameter Description Settings
05
Lock configuration (main control)
Set ONLY if installed bistable lock DAS802LOKB.
12= bistable lock
.
10= No lock, automatic setting.
11= Antipanic lock (locked with power – DAS802LOKA-LDP,
automatic setting).
12= Standard lock (locked without power (DAS802LOKB-
LDB) ,manual setting and bi-stable lock (DAS802LOK-
LD), automatic setting.
06
Lock release
00= Off.
01= On.
On DAS200RF set 01 .
If lock type is set manually (parameter 5), set 0 .
09
Central presence sensor test
00= None (factory setting).
01= Presence sensor 1 (set if a presence sensor with
monitoring is installed).
02= Presence sensor 1 and 2 (set if two presence sensors
with monitoring are installed).
12
Selection of opening direction
00= right hand opening for single door wing automation.
01= left hand opening for single door wing automation and
for double door automation (factory setting).
NOTE: On DAS200TRG this parameter cannot be set, the
opening direction is defined with the position of the belt
attachment bracket
16
Inner Impulse (motion) Monitoring
According to EN16005 or DIN18650 it is a demand to have
Inner impulse monitoring= On in escape routes.
00= Disables monitoring.
01= Enables monitoring.
NOTE: on DAS200TRF set to 01
.
NOTE: on DAS200TRG this parameter is set to 01 .
29
Side presence sensor test
00= None (factory setting)
01= Presence sensor 1 (set if a presence sensor with
monitoring is installed).
02= Presence sensor 1 and 2 (set if two presence sensors
with monitoring are installed).
67
Selection of the type of automation
00= Automation with one door wing
.
01= Automation with two door wings .
98
Lock Configuration, terminal 16-17
DAS902MP
NOTE: Set ONLY if installed bistable lock DAS802LOKB.
11= bistable lock
99
Function Select, terminal 6
DAS902MP
00= No function.
01= Disables Sustainable drive mode.
02= Enable the Mode Selector with a key (only COM500ER).
10. Start up
