11. Parameters
11.1 Configuration parameters according to function
For more information on the parameters, see paragraph 9.2
SPEED parameters
Parameter Description Range
00 High speed opening 10÷80cm/s
01 Low speed 05÷80cm/s
02 High speed closing 10÷80cm/s
TIME parameters
Parameter Description Range
03 Hold open time 00÷60s
04 Key hold open time 00÷60s
20 Partial hold open time 00÷60s
21 Push & Go hold open time 00÷60s
22 Auto width activation time 00÷60s
23 Auto width resume time 00÷60s
24 Jam hold time 00÷10s
25 Interlock disable time 00÷60s
26 Presence hold open time 00÷60s
92
(DAS902MP)
Open/Close timeout ref. terminal 4 00÷03
FUNCTION parameters
Parameter Description Range
5E Status indication. Off (00) / On (01) 00÷01
5F Default programming. Off (00) / On (01) 00÷01
12
Opening direction. 1 wing Right (00) / 1 wing Left or 2 wings (01).
On DAS200TRG not selectable
00÷01
13 Hold force 00÷60N
2A Side presence function. Safe speed (00) / Stop door (01) 00÷01
32 Active brake on stop. Off (00) / On (01) 00÷01
33 Push & Go in EXIT mode selection. Off (00) / On (01) 00÷01
34 Hold force in EXIT and OFF mode selection. Off (00) / On (01) 00÷01
35 Toggle operation mode selector after stop. Off (00) / On (01) 00÷01
53 Operator type. Slider (00) / mechanical emergency unit DAS200TRF (04) 00÷04
54 Service Needed Operating Hours 00÷60h x 1000
55 Service needed opening cycles
00÷50 x
100.000
60 Learn. Off (00) / On (01) 00÷01
61 Auto width. Off (00) / On (01) 00÷01
65 Sustainable Drive Mode. Off(00) / On(01) 00÷01
6A Interlock function. Off (00) / On (01) 00÷01
6B Synchronizing Function. Off(00) / On(01) 00÷01
6C External bus device ID 00÷99
