DITEC DAS200TRF User Manual

34
EN
IP2348EN
During this cycle, the following accessories connected to the control panel are recognised and
some parameters detected:
Accessory / Parameter Parameter number
High Speed Closing 02
Presence of block and type, except bistable lock 05, 06
Whether the sensors are monitored or not 9, 16, 29, 31, 91
Presence of battery and type 41
Power supply type 64
Door type 67
Measurement of width of passage opening -
Calculation of weight of door wing(s) (except for DAS200TRF) 68
Calculation of friction in the system 69
At the end of the learning cycle, the door remains closed and the display indicates .
If some parameters have not been automatically configured during the learning cycle, the door
opens. The display first indicates , and then the parameter that has not been acquired auto-
matically, for example, if the door is a 2-wing or 1-wing door (parameter 67).
These parameters must be configured by the installer and/or check that there are no obstacles
and friction which prevents correct learning.
1. Press the SELECT button to start to modify the parameters.
2. Press SELECT again to display the parameter value in flashing mode.
3. Select the correct value using the UP and DOWN buttons.
4. Press SELECT to confirm and program the selected value.
5. Continue to configure the other parameters that have not been acquired
6. Press LEARN/EXIT for more than 2 seconds and the display will indicate , after 2 seconds,
the door closes and is ready for operating.
If necessary, you can adjust the following main parameters:ain parameters:
Parameter Description Settings
00
High Speed Opening (cm/s) 10÷80cm/s
02
High Speed Closing (cm/s) 10÷80cm/s
03
Hold Open Time (00÷60s)
11
Partial opening (00-99%)
15
Run Program (01÷05)
Performance adjustment. Sets how fast or slow the
door shall accelerate or break.
01= Smooth, for light doors.
05= Max Performance. For heavy doors.
38
Convenience battery 24V,
DAS902BAT2 (00÷01)
00= Off
01= On
NOTE: on DAS200TRG this display is not visible and
is set to 00.
49
Opening Max Force (02÷23N x 10)
If the reopening maneuver occurs too abruptly, set
parameter 49 with a value lower than the factory value
(10), example 04 - 05.
• For other parameter variations, see the “Parameters” chapter.
• Make sure the installation complies with the current regulations and the essential requi-
sites laid down by the relevant authorities.
• At the end of the start-up close the cover and fix it with the appropriate screws, see chapter 5.1.
