DITEC DAS200TRF User Manual

37
EN
IP2348EN
LOCK parameters
06 Lock release. Off (00) / On (01) 00÷01
43 Opening delay for lock 00÷99s x0,1
44 EXIT lock. Off (00) / On (01) 00÷01
51 Push & Close. Off(00) / On (01) 00÷01
52 Push & Close Timeout 00÷99s x10
98
(DAS902MP)
Lock configuration terminal 16/17. No lock (10) / bistable (11) 10÷11
SENSOR parameters
Parameter Description Range
07 Presence impulse 1 configuration. N.O. (00) / N.C. (01) 00÷01
08 Presence impulse 2 configuration. N.O. (00) / N.C. (01) 00÷01
09 Presence impulse monitoring. None(00)/sensor 1(01)/sensor 1 and 2(02) 00÷02 units
16 Inner impulse (motion) monitoring. Off (00) / On (01) 00÷01
27 Side presence input 1 configuration. N.O. (00) / N.C. (01) 00÷01
28 Side presence input 2 configuration. N.O. (00) / N.C. (01) 00÷01
29 Side presence impulse monitoring. None (00) / sensor 1 (01) / sensor 1 and 2 (02) 00÷02 units
30 Side presence activation distance 00÷99dm
31 Sensor type.1-wire (00) / 2-wire (01) monitoring 00÷01
45 STOP function. Off (00) / On (01) 00÷01
46 STOP configuration. N.O. (00) / N.C. (01) 00÷01
91
(DAS902MP)
Function select terminal 4. No function (00) / Open / Close function (01) / Interlock
disable (02) / inner impulse 2 monitoring (03)
00÷04
93
(DAS902MP)
Function select terminal 2. No function (00) / Close function (01) / inner impulse
2 (03)
00÷03
OPERATION MODE SELECTOR parameters
Parameter Description Range
B0 Operation mode selector variant. Electronic program selector (04) 00÷04
B1 Operation mode selector key lock. Off (00) / Hold for 2 s.(01) /Passcode (02) / key (03) 00÷03
B2 Operator mode selector service indication. Off (00) / On (01) 00÷01
B3
Choose priority of the operation mode selector. The lower the number the higher
the priority.
25÷29
B4 Choose group of the operation mode selector. 00÷10
B5
Choose display mode of the operation mode selector. Show system mode (00) /
Show local mode (01)
00÷01
B6
Choose terminal mode of the operation mode selector. The buttons are disabled
(00) / adapts to system mode (01) / it si setting the operation mode (02)
00÷02
B7 Mode selector, self service indication. Off (00) / On (01) 00÷01
B8 Mode selector, key impulse. Disabled (00) / Login required (01) / Enabled (02) 00÷02
B9
Bluetooth Power Mode. Always disabled(00), Disabled in OFF mode(01), Always
enabled (02). Default(02)
00÷02
6F Choose group of the operation mode selector. 01÷10
97 Operation Mode Selector Function (unit DAS902MP). Off(00) / On(01) 00÷01
9A Priority of the operation mode selector (unit DAS902MP) 25÷99
9B Choose group of the operation mode selector (unit DAS902MP) 00÷10
