DITEC DAS200TRF - Page 57

57
EN
IP2348EN
25
Battery Error
The battery is disconnected, short circu-
ited or the internal thermal fuse in the
battery is defective. The charging current
is out of specification.
Make sure that the cables are OK and
connected.
Charge or replace the battery.
Replace the main control unit.
26
Emergency Action
Timeout
The door is prevented its emergency unit
test within a stated time, due to high
friction or jammed door.
Make sure that the door can open to the
fully open position.
Main error: E3 Electronic Unit Error
Detailed error Reason Remedy
00
RAM Error
Internal RAM memory error. RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
01
ROM Error
Internal ROM memory error. RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
02
EEPROM Error
Serious internal EEPROM memory error. RESET
If the problem remains, replace the main
control unit
05
Ambient Temperature
Error
Ambient temperature measurement
is wrong.
RESET, and if the problem remains, replace
the main control unit.
06
Brake Chopper Error
Not possible to activate brake chopper. RESET, and if the problem remains, replace
the main control unit.
08
A/D Converter Error
The internal A/D converter is broken. RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
10
Register Error
Internal register error.. RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
11
OS Error
Internal program error. RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
14
Lock Current Error
The lock is defective. Check that the right lock is installed, and
if the problem remains, replace the lock.
RESET, and if the problem remains, replace
the main control unit.
17
Hardware Watchdog
Error
It is not possible to disable the motor
bridge.
RESET, and if the problem remains, replace
the main control unit.
18
EEPROM Critical Write
Error
Internal write EEPROM memory error.
This error mainly occurs when it is
impossible to change a configuration
parameter.
RESET, and if the problem remains, replace
the main control unit.
22
24 V Over Current Error
The auxiliary 24 V output is overloaded. RESET, and if the problem remains, check
the connected sensors and other 24 V
accessories.
RESET, and if the problem remains, repla-
ce the electronic unit having a flashing or
extinguished LED.
23
Lock Circuit Error
It is not possible to disconnect the lock
with the lock relay.
RESET, and if the problem remains, replace
the main control unit.
24
Learn Error
The Learn cycle has timed out. Make sure that the door can make a full
open/close cycle. Check for high friction or
jammed door and then make a new Learn.
27
bistable ( LDB) lock
error
The LDB lock is defective. Check that the right lock is installed; if the
problem remains, replace the lock.
33
Flash Code Error
Serious internal programming error. RESET, and if the problem remains, replace
the main control unit.
