DISPLAY DESCRIPTION
Error code. Door is running without command
Service needed. Fatal error. Move the door manual to middle position without power. Change from
normal mode to programming mode on DIP switch no. 1. This will clear the SER error. If the door is
running again in 1 sec. without command when power is on then the PCB is defect.
E:0 1
Error code. Edge monitoring
Error code Monitoring failure of safety edge if this function is activated. Check or adjust safety edge list.
E:03
Error code. Run time
Error code. Door is stopped on run time control.
E:04
Error code. Service
Service counter decremented to 0
Reset for new countdown
E:05
Error code. Photocell
Failure in photocell circuit.
(Test cycle after last stop failed, Press STOP to start new test)
E:06
Error code. Safety Edge
Failure in edge circuit.
(Test cycle after last stop failed, Press STOP to start new test)
E:09
Error code. no change of encoder position, when running.
Door started, but the position is not changing.
Door is stopped after delay time and E:09 failure is shown about 1 sec.
Possible errors: The door is blocked, disengaged, cable connection error or the encoder magnet is
not fixed on the shaft.
Reset of E09: both limits shall be founded again by hold-to-run steps.
(If it is not possible to find both limits, the limits must be relearned)
If necessary, adjust in parameter 81 (delay time)
Parameter 81:03 = autoreset
E:20
Error code. EEPROM Fail
Possible error: Limits has been changed, after the force control has been learned.
Reset of E20: Try deactivating force control in parameter 41 ( 41:00 ) and after this make a new power-up
.
E:2 1
Error code. EEPROM Fail
EEPROM failure of power-up.
Try factory clear or change processor (paragraph 4.3).
fail
12u
24u
and
or
Error on 24V and/or 12V voltage circuit
24/12V is shorted or overloaded.
