5
IP2358EN
TECHNICAL DETAILS
Installation Vertical on a flat wall
Temperature range (operating) -10°C / +50°C
Humidity Up to 93% RH non-condensing
Degree of protection
IP54
PCB dimension 163x225x80mm
Supply voltage
3x400VAC; 50/60H; ± 10% L1,L2,L3,N,PE
3x230VAC; 50/60H; ± 10% L1,L2,L3,PE
Mains fuse max: 3 x 10A
Rated insulation voltage Ui = 400V
Transformer
Max 13 VA , VDE 0570/EN61558
Primary 230VAC winding is thermal protected by built-in thermal transformer fuse.
Both secondary windings are overload protected by multifuses.
Motor output
Max motor load by 3x400VAC: 4kW
Max motor load by 3x230VAC: 2.3kW
Max motor current: 8.5A
Emergency stop, Stop, Thermo spec.
door stop and Safety chain
Function as normal stop command and disconnect power to contactor coils
24VDC Output (terminals X3-18,X3-19) 24VDC ± 20% (non-regulated), Max load: 250mA
Safety edge input
PNE/air switch
Electric type - 8.2KΩ termination ± 10%
Optical type Performance level C, Category 2
Optical safety edge
Input voltage level high (green): 2.5 - 5.0V
Input voltage level low (green): < 0.5V
Input frequency range (green): 250 – 2000Hz (50% duty-cycle)
Pulse interval maximum (green): 7.0ms (when not 50% dutycycle)
Photocell input
X3-18, 22 or X12 1, 3 External photocell, 24VDC (e.g. self contain photocell)
Performance level C, Category 2
Electronic limits RS485, Data+ Data-, terminated with 120Ω
Relé (K3+ X17) Contatti Max 230VAC / 5A
Box dimension 210x305x120mm
