FlexxPump 125 (24V)
User Manual
44
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
6.3.12 FIL-Menu
The FIL-Menu allows you to trigger a dened multiple donation to FlexxPump 125. A
total of 40 pump strokes are initiated with the activation. This function enables you to
prell connected accessories (tubes, distributors, etc.) with the lubricant contained in
the lubricant cartridge, especially during the initial start-up of FlexxPump 125. However,
the process can also be aborted manually at any time.
There is no fault or error at FlexxPump 125.
Remove the activation and programming key from the bottom of the FlexxPump 125
and place it on the action area. The yellow LED will light up. Leave the activation and
programming key on the action area until FIL is displayed in the LCD. Remove the acti-
vation and programming key from the action area. The yellow LED disappears.
Ü The LCD ashes together with the green LED twice. The FlexxPump 125 starts
donating. The green LED lights up during each donation.
If you do not want to cancel the process: Insert the activation and programming key
into the hole provided on the underside of the FlexxPump 125.
ÜFlexxPump 125 dispenses 40 strokes of lubricant.
If you want to cancel the process: Place the activation and programming key on the
action area and wait until the end of a dispensing process (motor run).
ÜCLR appears in the LCD.
Remove the activation and programming key from the action area.
ÜFlexxPump 125 stops the FIL command.
Observe the back pressure values displayed on the LCD if they are of interest to you.
During the dispensing process, the green LED lights up; in addition, the counterpres-
sure for the stroke is displayed in the LCD.
The FIL-Menu can only be reached from the ON mode (FlexxPump 125 switched
