Description
Output signal (PIN 4) Detail
OFF
Switched off
low, permanent Chap. 6.3.3
PUL
Ready for operation
high, permanent Chap. 8
PUL ashing
Receiving control signal high, permanent Chap. 8
01...50
Dispensing process low, 10...18 Seconds Chap. 8
E1
Cartridge empty 0,5Hz-square wave signal, perma-
nent
Chap. 8.3.1
E1
No Cartridge low, permanent Chap. 8.3.2
E2
Overload low, permanent Chap. 8.3.3
E3
Undervoltage low, permanent Chap. 8.3.4
E4
Critical error low, permanent Chap. 8.3.5
8.3 Output signals/LCD messages - External control (PLC)
