FlexxPump 125 (24V)
User Manual
68
EN-
SCHMIERSYSTEME
DIRECT LUBRICATION SYSTEMS
D L S
1. Unscrew the empty cartridge from the
FlexxPump 125.
 Turn the empty cartridge counterclockwi-
se from the FlexxPump 125 and dispose it
properly after completion of the work.
 Pay attention to cleanliness during the
work. Make sure that dirt and foreign bodies
do not get into the lubricant inlet. If neces-
sary, carry out cleaning work beforehand
(chapter 9.1.2).
2. Mounting the new lubricant cartridge
 Place the full lubricant cartridge on the
FlexxPump 125.
 Turn the lubricant cartridge clockwise onto
the FlexxPump 125.
 The end position is reached after 2 full
rotations when the label of the lubricant
cartridge is aligned with the front foil of the
FlexxPump 125.
LCD
