DLS FlexxPump 250 DLS - Appendix; Dimension sheet and installation dimensions

revision: 1
FlexxPump 250/400 DLS
User Manual
52
EN-
11. Appendix
11.1 Dimension sheet and installation dimensions
33.5
ø6.6 (2x)
45.5
96
107
198.5
84
165
Abdeckung housing
Stopfen pin
ø13
Inlay inlay
Antriebseinheit pump unit
Schlauchanschluss 6 schwenkbar tube connection 6 turnable
30
88
94
110.6
M12x1
3.8
