1.6. Mother Board 4.0
M1 Power Supply
J16 Encoder Position
J9 Relevelling Circuit
J18 Env. Temperature
J12 Multiplex CAN
J10 Light Curtain / >|<
J26 Optional Boards
J21 Emergency Circuit
J19 PME Panel
J6 Parallel Signals
J8 UCM Circuit
J25 Batteries Test
J20 Out Spare
J11 Safety Chain
J4 FUJI Analog / Serial
J15 81-21 Circuit
J13 Car at floor
J14 Hydro command
J22 Motor Relay
J23 Brake Relay
FJ1 FUJI Interface
LED 1
LED 2
LED 3
LED 4
LED 5
LED 6
