ANNEX VIII: UCM Circuit
The following table shows how to set the UCM Monitor parameter according to the device or circuit for
detecting uncontrolled movements.
For Hydraulic installations the parameter is used for:
-) Central unit / valves configuration (see table VIII.2)
-) UCM solution managed by controller
Monitor UCM
Device / Hydraulic Control Unit
UCM Solution
Actuator
Tipo
Tempo
No
Not present
No
-
1
1,5 s
Overspeed Governor OSG A3 Montanari RQ-AXXX
Yes
Safety Gear
2
1,5 s
Controller = Brake monitor
Yes
A3 Certified
Brakes
3 29
Do not use
30
1,5
Hydro Central Unit with Electromechanical valves
(A3 second down valve is optional, no test performed)
Without UCM /
ELGO
-
31 79
Do not use
Table VIII.1 Monitor UCM
