” Menu
Table of Parameters
Time of car at floor without direction before taking
landing calls. In case of combined automatic doors,
timing starts when doors have closed and the shock,
photocell and re-opening contacts are not activated
Set the blinking for floor buttons upon registration
Permanent;
Flashing at floor
Selection of the output type on the 16 relays boards.
NOTE: 1 wire/floor and 1 wire/floor HYD configurations
are available only on first 16RL board.
After the two AUX board configuration can be set the
outputs on BDUs (OUT-1 and OUT-2).
1 wire per floor;
Car at floor;
Floor light;
Gray indicator;
9 segm. indicator;
Lift is coming
1 wire per floor
HYD;
BDU Inputs
Type 0 = Car at floor and Out of Service
Type 1 = Arrows
Type 2 = Car at floor and Car is coming
Type 3 = 3 Wire Display
The first setting s for all floors, the second setting can be
used for specific configuration floor by floor.
The BDU dynamic output is used also in case of PIT8
boards (parallel pre wired LOPs).
Type 0
Type 1
Type 2
Type 3
Automatic floor
designation
Automatic setting of numeric characters for serial
position indicators. The value increases/decreases
automatically at each floor starting from Lowest floor
Manual setting of alphanumeric characters for serial
position indicators. Setting must be done for each floor
Field Selection
Change value
It is possible to start trigger (speech synthesiser / next
direction arrows) on deceleration point (Yes) or to floor
arrival (No).
In case of parameter activation, arrow outputs are
activated only when lift stops at floor (or on slowing down
if trigger parameter on PV is active).
This function handle the delay between a floor/car call
and the light turning on. The output is deactivated XX
seconds after the call has been served.
0 sec means no timer active (light ON)
This function handles the
-) Type of automatic emergency operation (only VVVF):
• Type A = Nearest Floor in favourite direction
(depends by the load inside cabine)
• Type B = Only brake modulation (only for
Gearless 81-20 installations).
• Type C = On the main floor of the lift
(External UPS must be calculated on basis of
Installation characteristics)
• Type D = RNO for ship, evacuation on the fire
evacuation floor (No UPS). For Multiplex the
lifts will move once a time.
-) delay between the black out signal (IEME) and output
command (OEME) before system switch in automatic
emergency procedure.
Type A
Type B
Type C
Type D
---------------------
0 s <-> 30 s
Type A
----------------
0 sec.
