INSTALLATION
The control panel must be installed indoors with a pollution degree of no more than 2.
The enclosure of the control panel has an IP2X degree of protection.
The installation and maintenance of the control panel must be done by qualified and experienced personnel
after careful reading of the manuals and electrical diagrams supplied with the control panel.
Electrical protection must be carried out by means of Automatic circuit breaker and earth-leakage protection
coordinated with the earthing system which are the responsibility of the customer unless otherwise
specifically requested.
Refer to the electrical diagram supplied with the control panel for the following protection circuits:
- magnetothermic protection of the motor circuit
- magnetothermic protection of the safety circuit
- protection by fuses of all the other circuits
Measures for protection against electric shock:
- The control panel casing is metallic and must be connected to EARTH as indicated in the wiring diagram
supplied with the control panel.
- The command and control circuits (24V) are galvanically separated from the electrical network as indicated
in the electrical diagram supplied with the control panel.
- The safety circuit is galvanically separated from the electrical network as indicated in the electrical diagram
supplied with the control panel.
MAINTENANCE
For the maintenance of the control panel, refer to the manuals provided with the control panel and check
the status of the batteries of the alarm circuits and of the return to floor circuit (if present) during the periodic
inspections of the system.
For the transport and handling of the control panel, refer to the instructions on the packaging.
