5.6 “Doors” Menu
Table of Parameters
Cod.
Parameter
Description
Navigation
Values
Default
value
Ret. ramp on
Time before activation of the retiring ramp
▲
▼
Increase
Decrease
0,1 s <-> 9,9 s
0,1 s
Ret. ramp off
Time before deactivation of the retiring ramp
▲
▼
Increase
Decrease
0,1 s <-> 9,9 s
0,1 s
Lock fault time
Time before the activation of the lock fault
▲
▼
Increase
Decrease
2 s <-> 60 s
15 s
Door open delay
Time before door opening – for automatic door
▲
▼
Increase
Decrease
0,1 s <-> 9,9 s
0,5 s
Parking time with
open door
Lift car parking time with open door (in sec.)
▲
▼
Increase
Decrease
1 s <-> 30 s
7 s
Closing time with
calls
Time (in sec.) before door closes in case of registered
calls
▲
▼
Increase
Decrease
1 s <-> 60 s
2 s
Doors Nb.
Number and type of doors
◄►
Selection
-1 door
-2 doors simult.
-2 doors sel.
-2 doors
sel+through
1 access
Type Door A
Selection of door type for entrance A:
1) Manual / Not present: manual doors at floors, car
doors manual or not present;
2) Car independent: manual doors at floors, car doors
independent;
3) Car automatic: manual doors at floors, car doors
automatic;
4) Combined auto: automatic doors in the car and at
floors
◄►
Selection
Manual / not
present;
Car Independent;
Car automatic;
Combined Auto
Combined
Auto
Door A with limit
switch
Presence of a limit switch for door A (not present for
manual and independent doors)
◄►
Selection
No;
Yes NO
Yes NC
No
Select door A at
floor
Configuration of door A for each floor: set access to
each floor and open or close door parking at floor (for
automatic doors)
◄►
▲▼
Selection
Change floor
No;
Not enable
Pkg. Door close;
Pkg. Door open
Pkg. Door
close;
Door A
Open/Close time
Door A without limit switch: door opening/closing time
▲
▼
Increase
Decrease
1 s <-> 60 s
10 s
Door A start delay
Door A manual: time before start
▲
▼
Increase
Decrease
0,1 s <-> 9,9 s
2,0 s
Slipping Door A
Door A with limit switch: time before slipping fault
▲
▼
Increase
Decrease
1 s <-> 60 s
10 s
Door A powered
Door A powered during the run. Not considered for
manual or independent doors
◄►
Selection
No
Yes
Yes AT40
No
Type Door B
Selection of door type for entrance B (see Type Door
A):
◄►
Selection
Manual / not
present;
Car Independent;
Car automatic;
Combined Auto
Combined
Auto
Door B with limit
switch
Presence of a limit switch for door A (not present for
manual and independent doors)
◄►
Selection
No;
Yes
No
Select door B at
floor
Configuration of door A for each floor: set access to
each floor and open or close door parking at floor (for
automatic doors)
◄►
▲▼
Selection
Change floor
No;
Pkg. Door close;
Pkg. Door open
Pkg. Door
close
Door B
Open/Close time
Door B without limit switch: door opening/closing time
▲
▼
Increase
Decrease
1 s <-> 60 s
10 s
Floor 0 12:30:56
<Doors>
