5.10 “VVVF” Menu
This menu is available only when a FUJI FRENIC LIFT VVVF is connected to a Control Lift Board
VVVF Basic menu list Parameters
Cod.
Parameter
Description
Navigation
Values
Default values
F03
Maximum speed
Max speed of the motor
◄►
▲▼
Selection
Change Value
150-3600 RPM
1500 RPM
F05
Rated Voltage
Rated voltage of the motor driven by the
inverter
◄►
▲▼
Selection
Change Value
80-240 V
(for 200V class series)
230 V
160-500 V
(for 400V class series)
380 V
F07
Acc T1
Acceleration ramp (Only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change value
0,00-99,9 s
1,8 s
F08
Dec T2
Acceleration ramp (Only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change value
0,00-99,9 s
1,8 s
F42
Control Mode
Control Mode
◄►
▲▼
Selection
Change Value
0-1-2
0
(Geared drives, closed
loop)
1
(Gearless drives, closed loop)
2
(Geared drives, open loop)
E12
Acc/dec T5
◄►
▲▼
Selection
Change value
1,8 s
E13
Acc/dec T6
◄►
▲▼
Selection
Change value
1,8 s
E15
Acc/dec T8
◄►
▲▼
Selection
Change value
1,8 s
E16
Acc/dec T9
◄►
▲▼
Selection
Change value
0.00 – 99.9 s
1,8 s
C07
Creep Speed
Creeping speed (Only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change value
4,0 Hz
(Geared drives, open loop)
2,5 Hz
(Geared drives, closed loop)
1,5 Hz
(Gearless drives, closed loop)
C10
Middle Speed
System speed under inspection mode (Only
with FAI/FAS positioning system)
◄►
▲▼
Selection
Change value
25 Hz
(Geared drives)
10 Hz
(Gearless drives)
C11
High Speed
High speed for multistep speed change
(Only with FAI/FAS positioning system)
◄►
▲▼
Selection
Change value
50 Hz
(Geared drives)
20 Hz
(Gearless drives)
P01
Motor Poles
Number of poles of the motor
◄►
▲▼
Selection
Change value
(see motor plate)
4
(Geared drives)
20
(Gearless drives)
P02
Motor Rated Cap
Rated power of the motor
◄►
▲▼
Selection
Change value
(see motor plate)
Function of Inverter size
P03
Motor Rated Cur
Rated current intensity of the motor
◄►
▲▼
Selection
Change value
(see motor plate)
Function of Inverter size
P04
Motor Autotuning
Auto tuning of motor parameters (geared
drives only)
◄►
▲▼
Selection
Change value
0 (2 to trigger the auto
tuning procedure for
geared drives)
P06
M-No-Load Curr.
Motor no-load current
◄►
▲▼
Selection
Change value
Set by Motor Autotuning
(Geared drives)
0 A
(Gearless drives)
P12
M-Rated Slip
Rated slip frequency of the motor
◄►
▲▼
Selection
Change value
0-15Hz
Set by Motor Autotuning
Floor 0 12:30:56
<VVVF>
