Parameter
Description
Navigation
Values
Default values
L01
(*)
PG select
See Annex IV
◄►
▲▼
Selection
Change value
0-5
0
(Geared drives)
4
(Gearless drives with EnDat
Encoder)
5
(Gearless drives with sin-cos
Encoder)
L02
(*)
PG resolution
Resolution of the pulse encoder (Pulse/
Turn)
◄►
▲▼
Selection
Change Value
360-60000 P/R
1024
(Geared drives)
2048
(Gearless drives)
L19
S-Curve 1
S-Curve – 1
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L24
S-Curve 6
S-Curve – 6
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L25
S-Curve 7
S-Curve – 7
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L26
S-Curve 8
S-Curve – 8
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L27
S-Curve 9
S-Curve – 9
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L82
Brake On Delay
Delay from activation of BRKS output
◄►
▲▼
Selection
Change Value
0,00-10,00 s
0,20 s
L83
Brake Off delay
Delay from deactivation of BRKS output
◄►
▲▼
Selection
Change Value
0,00-10,00 s
0,10 s
VVVF Advanced menu list Parameters
Cod.
Parameter
Description
Navigation
Values
Default values
F01
Speed command
Command selection for speed variation
◄►
▲▼
Selection
Change Value
0=MULTISPEED
1=NR Analogic
(no polarized) no
available
0
(with FAI/FAS
positioning system)
1
(with Encoder positioning
systems)
F03
Maximum speed
Max speed of the motor
◄►
▲▼
Selection
Change Value
150-3600 RPM
1500 RPM
F04
Rated speed
Rated speed of the motor (Frequency)
◄►
▲▼
Selection
Change Value
50 Hz
F05
Rated Voltage
Rated voltage of the motor driven by the
inverter
◄►
▲▼
Selection
Change Value
80-240 V
(for 200V class series)
230 V
160-500 V
(for 400V class series)
380 V
F07
Acc T1
Acceleration ramp (only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change Value
0,00-99,9 s
1,8 s
F08
Dec T2
Deceleration ramp (only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change Value
0,00-99,9 s
1,8 s
F09
TRQ Boost
Torque increase
◄►
▲▼
Selection
Change Value
0,0-5,0
0,0
(up to 7,5 kW and from 30 kW)
0,3
(from 11 kW to 22 kW)
F10
Electronic OL
Overload electrical protection
◄►
▲▼
Selection
Change Value
1 - 2
2
F11
Overload Level
Electronic Thermal Overload Protection for
Motor (Value in Ampere equal to the
inverter size)
◄►
▲▼
Selection
Change Value
1 to 200%
(of the rated current)
100 %
F12
Overload time
Thermic time constant
◄►
▲▼
Selection
Change Value
0.5 – 75.0 min.
0,5
F20
DCBrake speed
Frequency threshold for DC INJECTION
0,2 Hz
(Open loop)
