DMG JUNIOR 4.0 - Page 41

User
Manual
File Name
Revision
Date
Page
93010350.EN_A_Junior 4.0 User
Manual_240828_v1.0 - VVVF
1.0
28/08/2024
41 / 90
Cod.
Parameter
Description
Navigation
Values
Default values
◄►
▲▼
Selection
Change Value
0,0 Hz
(Closed loop)
F21
DC Brake level
Intensity threshold for DC INJECTION
◄►
▲▼
Selection
Change Value
50 %
(Open loop)
0 %
(Closed loop)
F22
DC Brake T
DC INJECTION time
◄►
▲▼
Selection
Change Value
1,0 s
(Open loop)
0,0 s
(Closed loop)
F23
Starting Speed
Starting speed (in Hz) for the inverter
◄►
▲▼
Selection
Change Value
0,00-150
0,50 Hz
(Open loop)
0,00 Hz
(Closed loop)
F24
Holding Time
Holding time of running at starting speed for
the inverter
◄►
▲▼
Selection
Change Value
0,00-10 s
0,8 s
(FAI/FAS)
0,2 s
(Encoder)
F25
Stopping Speed
Stopping speed (in Hz) for the inverter
◄►
▲▼
Selection
Change Value
0,1 Hz
F26
Motor Sound
Carrier frequency)
◄►
▲▼
Selection
Change Value
15 kHz
F42
Control Mode
Control Mode
◄►
▲▼
Selection
Change Value
0-1-2
0
(Geared drives, closed loop)
1
(Gearless drives, closed loop)
2
(Geared drives, open loop)
F44
Current Limiter
Activation level of the current limiter.
% to the rated current of the inverter.
If “Auto”, value means no current limitation
◄►
▲▼
Selection
Change Value
100% 230% or
Auto
200 %
E04
Command X4
Input X4 not used
◄►
▲▼
Selection
Change Value
25
E05
Command X5
Input X5 not used
◄►
▲▼
Selection
Change Value
25
E06
Command X6
Input X6 not used
◄►
▲▼
Selection
Change Value
25
E07
Command X7
Input X7 not used
◄►
▲▼
Selection
Change Value
25
E08
Command X8
Input X8 not used
◄►
▲▼
Selection
Change Value
63
E10
Acc/dec T3
◄►
▲▼
Selection
Change Value
1,8 s
E11
Acc/dec T4
◄►
▲▼
Selection
Change Value
1,8 s
E12
Acc/dec T5
◄►
▲▼
Selection
Change Value
1,8 s
E13
Acc/dec T6
◄►
▲▼
Selection
Change Value
1,8 s
E14
Acc/dec T7
◄►
▲▼
Selection
Change Value
1,8 s
E15
Acc/dec T8
◄►
▲▼
Selection
Change Value
1,8 s
E16
Acc/dec T9
◄►
▲▼
Selection
Change Value
0.00 – 99.9 s
1,8 s
E20
Signal Y1
Output Y1 (transistor) not used
◄►
▲▼
Selection
Change Value
27
E21
Signal Y2
Output Y2 (transistor) not used
◄►
▲▼
Selection
Change Value
27
E22
Signal Y3
Output Y3 (transistor) not used
◄►
▲▼
Selection
Change Value
27
E23
Signal Y4
Output Y4 (transistor) not used
◄►
▲▼
Selection
Change Value
25
