Cod.
Parameter
Description
Navigation
Values
Default values
E30
Speed Arr. Hyst
Not used
◄►
▲▼
Selection
Change Value
0,48 Hz
(Geared motor)
0,1 Hz
(Gearless motor)
E31
Speed Det.Lev
Not used
◄►
▲▼
Selection
Change Value
48,33 Hz
E32
Speed Det Hyst
Not used
◄►
▲▼
Selection
Change Value
0,48 Hz
(Geared motor)
0,1 Hz
(Gearless motor)
E39
RRD Level
Recommended direction in emergency
(Not used)
◄►
▲▼
Selection
Change Value
0 %
E61
Analog Input 12
Function of analog input 12
◄►
▲▼
Selection
Change Value
0-2
1
E98
Command FWD
Function for screw terminal FWD
◄►
▲▼
Selection
Change Value
98
E99
Command REV
Function for screw terminal REV
◄►
▲▼
Selection
Change Value
99
C01
BATRY TL I
Torque limitation in emergency.
If “OFF”, value means no current limitation
◄►
▲▼
Selection
Change Value
0% 100% or
OFF
0
C02
BATRY TL T
◄►
▲▼
Selection
Change Value
0,0 s
C03
Battery Speed
Speed during emergency run
◄►
▲▼
Selection
Change Value
1,50 Hz
C07
Creep Speed
Creeping speed (only with FAI/FAS
positioning system)
◄►
▲▼
Selection
Change Value
4,0 Hz
(Geared drives, open loop)
2,5 Hz
(Geared drives, closed loop)
1,5 Hz
(Gearless drives, closed loop)
C10
Middle Speed
System speed under inspection mode (only
with FAI/FAS positioning system)
◄►
▲▼
Selection
Change Value
25 Hz
(Geared drives)
10 Hz
(Gearless drives)
C11
High Speed
High speed for multistep speed change
(FAI/FAS positioning system)
◄►
▲▼
Selection
Change Value
50 Hz
(Geared drives)
20 Hz
(Gearless drives)
P01
Motor Poles
Number of poles of the motor
◄►
▲▼
Selection
Change Value
(see motor plate)
4
(Geared drives)
20
(Gearless drives)
P02
Motor Rated Cap
Rated power of the motor
◄►
▲▼
Selection
Change Value
(see motor plate)
Function of Inverter size
P03
Motor Rated Cur
Rated current intensity of the motor
◄►
▲▼
Selection
Change Value
(see motor plate)
Function of Inverter size
P04
Motor Autotuning
Auto tuning of motor parameters (geared
drives only)
◄►
▲▼
Selection
Change Value
0 (2 to trigger the auto
tuning procedure for
geared drives)
P06
M-No-Load Curr.
Motor no-load current
◄►
▲▼
Selection
Change Value
Set by Motor Autotuning
(Geared drives)
0 A
(Gearless drives)
P07
M-%R1
Motor (%R1)
◄►
▲▼
Selection
Change Value
Set by Motor Autotuning
(Geared drives)
5 %
(Gearless drives)
P08
M-%X
Motor (%X)
◄►
▲▼
Selection
Change Value
Set by Motor Autotuning
(Geared drives)
10 %
(Gearless drives)
P09
M-Slip driving
Slip compensation gain in percentage to the
rated slip (P12) at the driving sides
◄►
▲▼
Selection
Change Value
0,0-200%
Set by Motor Autotuning
P10
M-Slip braking
Slip compensation gain in percentage to the
rated slip (P12) at the braking sides
◄►
▲▼
Selection
Change Value
0,0-200%
Set by Motor Autotuning
