5.3 “Faults” Menu
This Menu lists the last 60 faults stored into the internal memory of the controller. All faults are described
in the Troubleshooting section (§ 6).
WARNING: In case of black out, the internal memory is saved only if the battery is connected.
Fault
Description
Reset SE3
Limit switch fault; you can clear it only after closing Safety chain.
Reset 82212
Drift control
Reset RSP
RSP fault; for reduced pit and headroom.
Reset UCM
UCM fault; for A3 amendment
Reset ISO
ISO fault; problem detection in the operation monitoring of safety
module for advanced door opening / re-leveling.
Reset SCS
SCS Fault; installation 81-20.
Reset UAS
UAS Fault; Special function.
3/4: Error 3 of 4 total
43: Code/description error
(See list of faults in § 4
for explanations)
Pos.: Car position when the
fault was detected
# : Number of repetitions of
the same error
Cod.: Additional code
Date and time of last detection
* : Error still active
▲
▼
ENTER
▲
▼
ENTER
ENTER
No faults in memory
Reset all recorded faults
(press ENTER to confirm)
NOTE: faults are deleted
when lift cabin stops
Cancella l’errore rilevato relativo al Fine corsa
(premere ENTER per conferma)
NOTA: l’effettiva cancellazione in memoria
avviene solo ad impianto fermo
Floor 0 12:30:56
<Faults>
Floor 0 12:30:56
<Faults>
No faults
Floor 0 12:30:56
<Faults>
Faults : 4
Display ?
Floor 0 12:30:56
<Faults>
Faults : 4
Reset ?
Floor 0 12:30:56
<Faults>
Faults : 4
Reset XXX ?
< Faults > 3 / 4
43 = Inspection
Pos : 0 # 1 Cod. 0
17 / 03 / 09 10 : 10 *
Clear the detected error on the limit switch
(press ENTER to confirm)
NOTE: the actual cancellation occurs only
in memory system is stopped
