Cod.
Parameter
Description
Navigation
Values
Default values
P11
M-Slip T
Slip compensation time value (fixed)
◄►
▲▼
Selection
Change Value
0,2 s
P12
M-Rated Slip
Rated slip frequency of the motor
◄►
▲▼
Selection
Change Value
0-15Hz
Set by Motor Autotuning
P60
Armature
Resistance - Rs
◄►
▲▼
Selection
Change Value
Ohm
According Motor MX***
table
P62
Armature q-axis
reactance - Xs
◄►
▲▼
Selection
Change Value
Ohm
According Motor MX***
table
P63
Interphase
Inductive Voltage
- E
◄►
▲▼
Selection
Change Value
V
According Motor MX***
table
P65
q-axis inductance
magnetic
saturation
correction
◄►
▲▼
Selection
Change Value
%
According Motor MX***
table
H04
Auto reset Times
Auto-resetting (Number of times)
◄►
▲▼
Selection
Change Value
10
H05
Auto reset int
Auto-resetting (Reset interval)
◄►
▲▼
Selection
Change Value
5 s
H06
Cooling Fan
CTRL
Delay on Cooling Fan turning off
(Auto value means that there is no limit on
fan control; fan is always turned on)
◄►
▲▼
Selection
Change Value
0 min 100 min
or Auto
5 min
H57
S-Curve 11
Curve to S-11
◄►
▲▼
Selection
Change Value
0 – 50 %
20 %
H58
S-Curve 12
Curve to S-12
◄►
▲▼
Selection
Change Value
0 – 50 %
20 %
H64
Zero Hold Time
◄►
▲▼
Selection
Change Value
0,0 s
(with FAI/FAS positioning
system)
0,8 s
(with Encoder positioning
systems)
H65
Soft Start Time
◄►
▲▼
Selection
Change Value
0,0 s
(with FAI/FAS positioning
system)
0,0 s
(with Encoder positioning
systems)
H67
Stop Hold Time
◄►
▲▼
Selection
Change Value
0,00 s
(Open loop)
1,00 s
(Closed loop)
H96
Brake Monitor
Enable Brake monitor
◄►
▲▼
Selection
Change Value
0-1
0
H190
Motor UVW order
Sequenza fasi uscita motore
◄►
▲▼
Selection
Change Value
0-1
1
L01
(*)
PG select
See annex IV
◄►
▲▼
Selection
Change Value
0-5
0
(Geared drives)
4
(Gearless drives with EnDat
Encoder)
5
(Gearless drives with sin-cos
Encoder)
L02
(*)
PG resolution
Resolution of the pulse encoder (Pulse/
Turn)
◄►
▲▼
Selection
Change Value
360-60000 P/R
1024
(Geared drives)
2048
(Gearless drives)
L03
(*)
P.P.Tuning
See annex IV
◄►
▲▼
Selection
Change Value
L04
(*)
P.P.Offset
Magnetic Pole Position Offset (Offset angle)
for gearless drives
◄►
▲▼
Selection
Change Value
Automatically set during
Pole Position Tuning
(L03)
L05
(*)
ACR P gain
◄►
▲▼
Selection
Change Value
1,5
L07
(*)
Automatic pole
tuning selection
◄►
▲▼
Selection
Change Value
According Motor MX***
table
