Cod.
Parameter
Description
Navigation
Values
Default values
L19
S-Curve 1
L19 to L28 specify S-curve zones to be
applied to operations driven by multistep
speed commands with S-curve
acceleration/deceleration.
◄►
▲▼
Selection
Change Value
20 %
(Geared drives)
25 %
(Gearless drives)
L20
S-Curve 2
20 %
(Geared drives)
25 %
(Gearless drives)
L21
S-Curve 3
20 %
(Geared drives)
25 %
(Gearless drives)
L22
S-Curve 4
20 %
(Geared drives)
25 %
(Gearless drives)
L23
S-Curve 5
20 %
(Geared drives)
25 %
(Gearless drives)
L24
S-Curve 6
20 %
(Geared drives)
25 %
(Gearless drives)
L25
S-Curve 7
20 %
(Geared drives)
25 %
(Gearless drives)
L26
S-Curve 8
20 %
(Geared drives)
25 %
(Gearless drives)
L27
S-Curve 9
20 %
(Geared drives)
25 %
(Gearless drives)
L28
S-Curve 10
20 %
(Geared drives)
25 %
(Gearless drives)
L29
SFO Hold T
Short Floor Operation (Holding time)
Only used for FAI-FAS positioning mode
◄►
▲▼
Selection
Change Value
0,00 s 10,00s
or OFF
OFF
L30
SFO Speed
Short Floor Operation (Allowable speed) –
NOT USED
◄►
▲▼
Selection
Change Value
0,00 s
L36
(*)
ASR P Gain High
See annex V
◄►
▲▼
Selection
Change Value
10,00
(Geared drives)
2,50
(Gearless drives)
L37
(*)
ASR I Gain High
See annex V
◄►
▲▼
Selection
Change Value
0,100
L38
(*)
ASR P Gain Low
See annex V
◄►
▲▼
Selection
Change Value
10,00
(Geared drives)
2,50
(Gearless drives)
L39
(*)
ASR I Gain Low
See annex V
◄►
▲▼
Selection
Change Value
0,100
L40
(*)
Switch Speed 1
Not used
◄►
▲▼
Selection
Change Value
5,00
(Geared drives)
1,00
(Gearless drives)
L41
(*)
Switch Speed 2
Not used
◄►
▲▼
Selection
Change Value
10,00
(Geared drives)
2,00
(Gearless drives)
L42
(*)
ASR-FF Gain
◄►
▲▼
Selection
Change Value
0.000 – 10.000 s
0.000 s
L55
(*)
TB Start time
◄►
▲▼
Selection
Change Value
0.00 – 1.00 s
0.20 s
L56
(*)
TB End time
◄►
▲▼
Selection
Change Value
0.00 – 20.00 s
0.20 s
