L64
(*)
TB Digital 3
◄►
▲▼
Selection
Change Value
-200 - +200 %
0 %
L65
(*)
ULC operation
Unbalanced load Compensation
◄►
▲▼
Selection
Change Value
0-1
1
L66
(*)
ULC activation
Unbalanced load compensation (Activation
time)
◄►
▲▼
Selection
Change Value
0,01-2,00 s
2,00 s
L68
(*)
ULC ASR P gain
See annex V
◄►
▲▼
Selection
Change Value
10,00
(Geared drives)
2,50
(Gearless drives)
L69
(*)
ULC ASR I gain
See annex V
◄►
▲▼
Selection
Change Value
0,100
(Geared drives)
0,005
(Gearless drives)
L73
(*)
APR P gain zero
See annex V
◄►
▲▼
Selection
Change Value
0
L74
(*)
APR D Gain
◄►
▲▼
Selection
Change Value
0,0
L75
(*)
Filter Time
◄►
▲▼
Selection
Change Value
0,000 s
L76
(*)
ACR P constant
◄►
▲▼
Selection
Change Value
0,00
L80
Brake mode
Brake Control (BRKS) output mode
◄►
▲▼
Selection
Change Value
1-2
1
L81
Brake On Level
Output current that turns the BRKS signal
ON when L80 = 2.
◄►
▲▼
Selection
Change Value
0,-200% of motor
no-load current
100 %
L82
Brake On Delay
Delay from activation of BRKS output
◄►
▲▼
Selection
Change Value
0,00-10,00 s
0,20 s
L83
Brake Off delay
Delay from deactivation of BRKS output
◄►
▲▼
Selection
Change Value
0,00-100 s
0,10 s
L84
BRKS check t
Allowable time between BRKS output and
BRKE input (Er6)
◄►
▲▼
Selection
Change Value
0,00-10 s
0,00 s
L99
ACTION SEL
Not used
◄►
▲▼
Selection
Change Value
L122
Del. Op. Input
Power Det. Level
◄►
▲▼
Selection
Change Value
%
L124
Del. Op. Dir. Calc.
Delay Timer
◄►
▲▼
Selection
Change Value
s
L130
Sheave diameter
(Ds)
◄►
▲▼
Selection
Change Value
mm
According Motor MX***
table
L131
Encoder diameter
(De)
◄►
▲▼
Selection
Change Value
mm
According Motor MX***
table
L132
Theta
compensation
band
◄►
▲▼
Selection
Change Value
deg
According Motor MX***
table
L133
Theta
compensation
gain lower limiter
◄►
▲▼
Selection
Change Value
According Motor MX***
table
L134
(*)
Backlash Time
Backlash Time
(When L65 = 2)
◄►
▲▼
Selection
Change Value
0,00-10,00 Sec
0
L198
Op. set switch 1
BIT0 = It is possible to fix the carrier
frequency to 16 kHz for the whole speed
range in order to reduce driving noise.
◄►
▲▼
Selection
Change Value
0
L199
Op. set switch 2
Reserved.
◄►
▲▼
Selection
Change Value
0
(*)
not available on LM2C Inverters model.
NOTE: Please consult the time diagram at the end of this manual, to better understand some
meaning parameters.
