Table of Parameters (Encoder positioning system)
Cod.
Parameter
Description
Navigation
Values
Default values
Positioning
system
Type of positioning system: with Encoder or
traditional. Note: Can only be modified in
Temporary Oper. mode
◄►
Selection
Encoder
Clockwise;
Encoder Counter
clockwise
Encoder ELGO
Encoder Clockwise
Autosetting
Start of floor position self-learning procedure.
Can only be modified in Temporary Operation
mode. See § 2.1 for details
◄►
Selection
No;
Yes
No
Floor Position
Position value for each floor
▲
▼
◄►
increase
decrease
Floor pos.
selection
Accel. Time
Acceleration time. Time required to switch from
start speed to travelling speed.
▲
▼
increase
decrease
1,0 s <-> 5,0 s
3,0 s
Starting Boost
Starting speed
▲
▼
increase
decrease
0 % <-> 10 %
3 %
Stopping Boost
Final (stopping) speed
▲
▼
increase
decrease
0 % <-> 10 %
4 %
Max speed
Maximum speed during the travel
▲
▼
increase
decrease
5 % <-> 100 %
100 %
Inspection
speed
Travelling speed in inspection mode
▲
▼
increase
decrease
5 % <-> 100 %
50 %
AGB/AGH
speed
Travelling speed on AGB/AGH limit points. Same
speed adopted during emergency operations
▲
▼
increase
decrease
1 % <-> 15 %
10 %
Delay Dir.-BRK
VVVF: Delay between activation of travel
direction and BRK command (start)
▲
▼
increase
decrease
0,0 s <-> 3,0 s
0,5 s - VVVF
0,0 s - Others
OLEO: Star / Delta delay
▲
▼
Increase
Decrease
0,0 s <-> 3,0 s
0,5 s – VVVF
0,5 s – Star/Delta
0,0 s - Others
Delay BRK-S
Delay between activation of BRK command and
beginning of the analogic speed ramp
▲
▼
increase
decrease
0,0 s <-> 3,0 s
0,3 s - VVVF
0,0 s - Others
Delay BRK-Dir.
Delay between deactivation of run command and
deactivation of travelling direction (stop at floor)
▲
▼
increase
decrease
0,0 s <-> 3,0 s
1,5 s - VVVF
0,0 s - Others
Emergency
BRK On
Emergency break modulation parameter
▲
▼
increase
decrease
0,0 s <-> 5,0 s
0,0s
Emergency
BRK Off
Emergency break modulation parameter
▲
▼
increase
decrease
0,0 s <-> 5,0 s
0,0s
Monitor
Encoder
Contains information on:
Encoder features, reading of slowdown heights
(R1D / R1S), re-levelling (RRIPD / RRIPS) and
stop of the cabin (RLD / RLS) where D indicates
down while S means up; finally it contains info on
reading AGB / AGH and ZP heights.
Note: R1D and R1S heights can be modified
pushing Enter without repeating self learning
procedure (to let the slowing down distance be
equal in rise and descent).
NOTE: Please consult the time diagram at the end of this manual, to better understand some
parameter meanings.
