Parameter
Description
Navigation
Values
Default
value
Calls from
16IO
Special Features to use screw terminal interface by 16IO board
instead of Prewired COP board (DMCPIT) when you have partial
modernization.
The Interface can be used
- on single board on the first (16IO I option) or on the second
(16IO II option) interface board managing up to 12 floors
- on two interfaces (16IO I+II option) managing up to 28 floors.
NOTE: This option could be not compatible if 16IO board is used
for other functions
.
◄►
Choice
Disabled;
16IO I;
16IO II;
16IO I+II;
Disabled
Type of
Installation
Type of installation (Simplex / Multiplex / Multiplex LIGHT)
Multiplex LIGHT has a shared single BDU line for two lifts with a
dedicated sinalization’s wiring.
◄►
Choice
Simplex;
Multiplex;
Multiplex LIGHT
Simplex
Multiplex
configuration
Multiplex configuration: Lift No.(LN); Push-Buttons Line (PBL);
Floors in multiplex; Offset.
For description, refer to Appendix I.
◄►
▲▼
Select param.
Change value
- Lift No (LN).: 1<->4
- PushButtons Line (PBL):
0(1 Line)<->3(4 Lines)
(LN).(PBL):
1.0
- Floors: 2 <-> 16 [32]
- Ofst 0 <-> N° floors
Flrs. : 2
Ofst : 0
Multiplex
Call
In multiplex installations a floor call can be differentiated with a
long push-button pressure (more than 3 seconds) calling:
a) The installation with lower "Lift No (LN)" parameter (for
example if there is a duplex installation with a big cabin
for disabled passengers and a smaller one, the greater
must be set as "1" and the other as "2";
b) In an “asymmetric floor distribution” system, the
installation that can reach the lowest/highest level.
◄►
Choice
No (0, 1, 2, 3);
Yes (0, 1, 2, 3)
No
