COP Measures
Analogic measures
◄►
ESC
Change page
Exit
MAIN_A = COP A power supply
MAIN_B = COP B power supply
T_CAR = Cabine temperature
FLOORS Line
BDU
Communication Line
ENTER
ESC
Reset
Exit
Error: Communications error number
FER: Frame Error Rate
Date and hour of last reset
CAR Line
TOC / COP
Communication Line
ENTER
ESC
Reset
Exit
Error: Communications error number
FER: Frame Error Rate
Date and hour of last reset
MTPX Line
MULTIPLEX
Communication Line
▲▼
ENTER
ESC
Change page
Reset
Exit
Error: Communications error number
FER: Frame Error Rate
Date and hour of last reset
ELGO model:
ELGO’s Diagnostic
PLAYBOARD IN-OUT table description parameters
Input
Description
Input
Description
SE0
Safety chain Start
REV
REV1
REV2
Inspection function (machine room)
Inspection function (Top of Car)
Inspection function (PIT)
SE1
Safety chain pit safety contacts
REM
REM1
REM2
Inspection up (machine room)
Inspection up (Top of Car)
Inspection up (PIT)
SE2
Safety chain top of car inspection Box/Stop
RED
RED1
RED2
Inspection down (machine room)
Inspection down (Top of Car)
Inspection down (PIT)
SE3
Safety chain final limit switch, safety gear,
speed governor
TH1
TH2
Motor (Oil) temperature sensor control
SE4
Safety chain hall doors preliminary contacts
IEME
Emergency (power supply failure)
SE5
Safety chain hall doors inerlocks
PME
PME selector (emergency evacuation)
SE6
Safety chain car doors contacts and pre
trigger device (81-21)
AGH
AGB
Top deceleration switch
Bottom deceleration switch
CCO
CCOB
power contactors control
FAS
FAI
Position Sensors (no encoder positioning
system)
CISO
Monitor ISO relay
E511
Optional input for Shaft Access
TISO
Safety Module SM1 control
BYPL
BYPC
Door’s safety Bypass selector
LE
Emergency Light (car light power supply)
BRA
Door open button (entrance A)
BFR
door close button
CEA
Photocell entrance A
PCA
car priority function
FOA
Door open limit switch entrance A
POM
Fire-fighters operations (Hall key switch)
FFA
Door close limit switch entrance A
CPOM
Fire-fighters operations (Car key switch)
BRB
Door open button (entrance B)
SUR
Overload control
CEB
Photocell entrance B
COM
Full load control
FOB
Door open limit switch entrance B
HS
out of service function
FFB
Fine corsa chiusura (Porta B)
ZP
door zone signal
BR1
Brake 1 monitor switch
RPH
Phase sequence control
BR2
Brake 2 monitor switch
IN_A
Monitor UCM circuit
IN_D
Monitor UCM circuit
Output
Description
Output
Description
VHS
Output - out of order illumination
DSA
Output - alarms de-activation
RMV
Output – intermediate speed command
511B
Output - Norm 511 Buzzer
