N.
Fault
Type
Description
Remedy
41
Fault ISO
Problem detected in the operation
monitoring of safety module for
advanced door opening / re-leveling.
If activated, the installation goes into
“out of service” mode at the top floor
(electric) or bottom floor (hydro).
Cod. 10: Monitor Relay RISO fail
Cod 100: fail on Safety module
monitor during travel
Cod 200: fail on Safety module
monitor at level
Check the alignment of ISO1 and ISO2.
Reset ISO in the menu Faults (§ 5.3).
42
TOC
Communication
No serial link between controller and
car (in case of car serial link system
configuration)
Check CAN link between controller and
top of car board
43
Inspection
The system is in Inspection mode
(NORM/ISP switch set to Inspection)
EN 81.1/2
Cod 1: REV input open (STD Version)
Cod 2: TOC’s REV1 input open
Cod 3: REV + TOC’s REV1 input
open
Cod 5: REV input open (Pitagora
version)
Cod 6: REV1 input open
Cod 7: REV + TOC’s REV1 input
open
EN 81.20
Cod 11: PME inspection (REV)
Cod 12: TOC inspection (REV1)
Cod 13: PME + TOC inspection (REV
+ REV1)
Cod 14: PIT Inspection (REV2)
Cod 15: PME + PIT Inspection (REV
+ REV2)
Cod 16: TOC + PIT Inspection (REV1
+ REV2)
Cod 17: PME + TOC + PIT Inspection
(REV + REV1 + REV2)
To exit the inspection mode move the
NORM/ISP switch to Normal and close
the safety chain to trigger the reset
procedure
