Code
Alarm Name
Sub Code
Description
OH4
Motor Protection (PTC thermistor)
1
PTC thermistor
2
NTS thermistor
OH6
Charging resistor overheat
1
Charging resistor overheat
Except for FRN0039LM2A-4 / FRN0045LM2A-4
11
Thermistor disconnection (NTC3)
OL1
Motor overload
0
Current detection electronic thermal
LV
Undervoltage
1
Undervoltage is occurred during gate ON
11
Minimum level of battery operation
dbH
DB resistor overheat
0
DB resistor overheat
1
DB transistor 2sec_ON continuously
dbA
DB transistor failure detection
0
DB transistor failure detection
Er1
Memory Error
0x0001
Alarm history destruction
0x0002
Standard function code
0x0004
User function code
0x0008
Hidden function code
0x0010
Program area error
0x0040
Reading mismatch (retry over)
0x0080
Writing mismatch (retry over)
0x0100
Extended area
0x1000
Adjustment value area
Er2
Keypad panel communication error
1
Disconnection detection
Er3
CPU error
1
CPU re-start processing
1000
Function code checksum error (RAM error)
0x0001
Standard function code error
0x0002
Hidden function code (u code) error
0x0004
Hidden function code (n code) error
0x0008
Adjustment valve function code error
0x0010
Extended area
2000
Fixed-cycle error
0x0001
L1 cycle error
0x0004
L3 cycle error
0x0008
L4 cycle error
0x0020
L6 cycle error
0x0080
LP cycle error
3000
Unjust cut in
5001
Outside RST input
7001
Stack area destruction
9000
Software failure detection
0x0200
Alarm QUE over
F50  F52
Wrong R (too high)
