Code
Alarm Name
Sub Code
Description
Ert
CAN communication error
1
Bus-off
2
Guarding timeout detection
OLU
Inverter overload
1
IGBT protection
2
Inverter thermal
Only FRN0060LM2A-4  FRN0091LM2A-4
10
ΔTj-c ≥ 60 °C
ECF
EN circuit error
10
EN input error (_EN1A=L, EN2A=L)
11
EN input error (_EN1A=H, EN2A=H)
5000
Diagnosis circuit error
5010
P5S power supply failure
5020
CPU diagnosis: Port setting diagnosis
5030
CPU diagnosis: ROM diagnosis
5040
CPU diagnosis: RAM diagnosis
5050
CPU diagnosis: sequence monitor
ECL
Customization logic malfunction
0
Customization logic error
Err
Simulated failure
9998
Simulated failure
Ot
Torque excessive error
0
Torque excessive error
bbE
Mechanical brake error
11
BRAKE1 error
12
BRAKE2 error
Eo
EN terminal error
0
EN terminal error
rbA
Rescue speed detection error
0
Rescue speed detection error
tCA
Direction switch limit arrival
0
Direction switch limit arrival
SCA
Short circuit error
0
Short circuit error
Lco
Load cell error
0
Load cell error
EF
Ground protection
0
Three phase current
Only FRN0060LM2A-4  FRN0091LM2A-4
